DATEL ADS-1011 Analog to Digital Converter

Hermetically Sealed for Hi-Rel, Precision Applications

March 25, 2014
- 10-bit resolution
- High-reliability version available
- Less than 2mW @ 50kHz throughput
- 2.5µs conversion time
- +2.7 to +5.5 Vdc operation

The DATEL Business Unit of Murata Power Solutions has announced the introduction of the ADS-1011 series, a new line of Analog-to-Digital converters that are 10-bit resolution and housed in a 24-pin LCC hermetically sealed ceramic package.

Each unit features guaranteed no missing codes and is 100 percent tested for performance across one of three standard temperature ranges: 0 to +70°C; -40 to +100°C; -55 to +125°C. The ADS-1011 can run from as low as +2.7 Volts up to +5.5 Volts supply.

The ADS-1011 offers a unique architecture that includes a sample-hold, successive approximation ADC, and high speed microprocessor-compatible serial data transfer, while consuming less than 10mW of power at 250 kHz throughput. The ADS-1011 is rated to withstand a minimum of 30k Rad. It features 60 dB of SNR and -65 dB of total harmonic distortion. With excellent Differential and Integral Non-linearity specifications, the ADS-1011 should be considered where precision and reliability are required.

The ADS-1011 series is manufactured in DATEL’s USA facility, which is certified to MIL-PRF-38534 standards. The device is available in commercial as well as military/high-reliability versions. RoHS and non-RoHS versions are available.

Further editorial information from:
Tony Khazen
Title: DATEL Business Unit Director
DATEL
Tel: +1-508-964-5251
E-mail: tonykhazen@datel.com

Contact details for publication:
DATEL
11 Cabot Boulevard
Mansfield, MA 02048-1151, USA
Tel: +1-508-339-3000
e-mail: tonykhazen@datel.com

About DATEL (www.datel.com)

Dedicated to the military and aerospace market solutions, DATEL is a business unit of Murata Power Solutions. For several decades DATEL has worked closely with defense and Hi-Rel companies to provide fully qualified and MIL Certified 883 components that meet customers' specific and stringent application requirements.

DATEL data acquisition products are designed and manufactured in an 180,000 square-foot, MIL-PRF-38534 hybrid certified fabrication facility located in Mansfield, Massachusetts, USA. The data acquisition product offering has grown to become one of the industry's broadest, designed to meet the ever-changing requirements of military, HI-REL, medical, scientific and industrial applications. DATEL are ISO-9001 certified, and ITAR registered.

DATEL, Inc. is a leading supplier of High Precision Data Acquisition Components and DC to DC converters. Our leadership status in high-performance data acquisition components is unchallenged, driven in large part by our engineering expertise to develop solutions with outstanding electrical performance, small packaging, low power consumption and ease of use. These products employ five basic technologies: monolithic IC, thin-film hybrid, thick-film hybrid, SMT technologies and discrete component circuit.

DATEL's DC DC converter product line includes non-isolated point-of-loads dc/dc, switching regulators as well as a complete line of industry standard brick packages (Sixteenth-Brick, Eighth-Brick, Quarter-Brick, Half-Brick and Full-Brick) and railway dc-dc converters.

Diminishing Manufacturing Sources and Material Shortages (DMSMS): We have the solution to your Diminishing Manufacturing Sources and Material Shortages (DMSMS) component problems. DATEL has the design knowledge and manufacturing capabilities to provide alternative solutions to on-going and mature defense and aerospace programs which suffer from Diminishing Supplier-Base issues.
